Orikam Curing Pen-E Light Cure Unit - 3 LEDs

The Orikam Curing Pen-E Light Cure Unit with 3 LEDs is engineered for optimal polymerization across a diverse array of restorative dental procedures. This cordless, pen-style device is specifically intended for curing dental resins and composites, facilitating the hardening and bonding of dental materials such as composites, sealants, and bonding agents to tooth structures.

Featuring Tri-LED technology, the unit delivers uniform curing with a broad spectral range of 380 nm to 515 nm. This wide spectrum ensures effective curing of various resins, including those utilizing alternative initiators like TPO, which are activated by wavelengths below 410 nm, in addition to common camphorquinone (CQ) materials.

Manufactured by Changzhou Sifary Medical Technology Co. Ltd., the Curing Pen-E Light Cure Unit adheres to stringent quality and performance standards. The CuringPen Dental Curing Light family, to which this unit belongs, complies with the performance requirements established by ISO 10650:2018 and has undergone a 510(k) premarket notification process with the U.S. Food & Drug Administration (FDA), indicating substantial equivalence for its intended use in hospital environments, clinics, or dental offices by qualified personnel.

• Preparation

  • Fully charge the device before use.

  • Select the appropriate light intensity based on the material being cured.

• Positioning

  • Hold the pen close to the restoration area, maintaining the recommended distance from the surface.

• Curing

  • Activate the curing light using the control button.

  • Use the digital timer to ensure the correct exposure time per manufacturer’s material instructions.

• Completion

  • Switch off the unit after curing.

  • Recharge as needed before the next use.

• Maintenance

  • Clean the light tip with a suitable disinfectant after each procedure.

  • Store in a cool, dry place when not in use.
