Brand: Niscomed

Country of Origin: India

What's in the Box

Main ECG Machine Unit ×1 Patient Cable ×1 Limb Electrodes Set (4 pcs) ×1 Chest Electrodes Set (6 pcs) ×1 Power Cable ×1 80mm x 20M Recording Paper ×1 Paper Axis ×1 Power Cord ×1

Electrocardiograph 304 ECG Machine is a compact and lightweight ECG machine featuring a 7-inch high-resolution color touch screen. It supports simultaneous acquisition and display of 12 leads, automatic ECG measurement and interpretation, digital filtering, and resistance to baseline drift, AC, and EMG interference. It also supports USB flash disk and micro SD card for extended memory and software upgrades.

Key Features

  • 7-inch high-resolution color touch screen
  • 12-lead simultaneous acquisition and display
  • Automatic ECG measurement and interpretation
  • Digital filters for baseline drift, AC and EMG interference
  • Compact and lightweight design
  • USB flash disk and micro SD card support
  • Software upgrade via USB/SD card
  • Built-in rechargeable Li-ion battery



Lead Standard 12 Leads
Acquisition Mode Simultaneous 12-lead acquisition
Measurement Range ±5 mVpp
Input Circuit Floating; Protection circuit against defibrillator effect
Input Impedance ≥50 MΩ
Input Circuit Current <0.05 µA
Record Mode Automatic: 3CH×4+1R, 3CH×4, 3CH×2+2CH×3, 3CH×2+2CH×3+1R, 6CH×2; Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; Rhythm: Any lead selectable
EMG Filter 25 Hz / 30 Hz / 40 Hz / 75 Hz / 100 Hz / 150 Hz
DFT Filter 0.05 Hz / 0.15 Hz
AC Filter 50 Hz / 60 Hz
CMRR >100 dB
Patient Leak Current <10 µA (220V–240V)
Frequency Response 0.05 Hz–150 Hz (-3 dB)
Sensitivity 2.5 mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV (Error: ±5%)
Anti-Baseline Drift Automatic
Time Constant ≥3.2 s
Noise Level <15 µV p-p
Paper Speed 12.5 mm/s, 25 mm/s, 50 mm/s
Recording Mode Thermal printing system
Paper Specification Roll 80 mm × 20 m
Safety Standard IEC I/CF
Sample Rate Normal: 1000 sps/channel
Power Supply AC: 100–240 V, 50/60 Hz, 30 VA–100 VA
DC Power 14.8 V / 2200 mAh, built-in lithium battery





1 Year warranty
